Electromagnetic flow meters

50000 INR/Number

Get a Price/Quote

Product Details:

Product Type Electromagnetic Flow Meter
Material Carbon Steel, Stainless Steel with PTFE / Rubber lining
Usage Liquid Flow Measurement
Application Industrial, Water Treatment, Chemical Plants, Food & Beverage, Pharmaceuticals
Size 15mm to 600mm (customizable)
Weight Approx. 2 kg to 25 kg depending on size
Color Blue / Grey (as per manufacturer standard)
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Electromagnetic flow meters Price And Quantity

Price 50000 INR/Number
Minimum Order Quantity 10 Number

Ingress Protection IP65 / IP68
Output Signal 4-20 mA, Pulse, RS485 MODBUS (optional)
Protection Class Compact/Remote type available
Display LCD with Totalizer
Flow Velocity Range 0.3 to 10 m/s
Lining Material PTFE, Hard Rubber, Neoprene (as per media compatibility)
Communication Option HART, MODBUS, Profibus (optional)
Accuracy 0.5% of Reading
Minimum Conductivity of Fluid 5 S/cm
Electrode Material SS316 / Hastelloy / Titanium (optional)
Repeatability 0.2%
Process Connection Flanged (ANSI/DIN/BS), Others on request
Operating Temperature -10C to +80C (higher with special lining)
Power Supply 90-265 VAC or 24 VDC

Electromagnetic flow meters Product Specifications

Size 15mm to 600mm (customizable)
Material Carbon Steel, Stainless Steel with PTFE / Rubber lining
Product Type Electromagnetic Flow Meter
Weight Approx. 2 kg to 25 kg depending on size
Usage Liquid Flow Measurement
Application Industrial, Water Treatment, Chemical Plants, Food & Beverage, Pharmaceuticals
Feature Accurate measurement, No moving parts, Maintenance free, Digital display, Corrosion resistant lining
Tensile Strength Not Applicable (non-load bearing component)
Color Blue / Grey (as per manufacturer standard)
Capacity 10 LPH to 10,000 m3/hr (as per model)

Ingress Protection IP65 / IP68
Output Signal 4-20 mA, Pulse, RS485 MODBUS (optional)
Protection Class Compact/Remote type available
Display LCD with Totalizer
Flow Velocity Range 0.3 to 10 m/s
Lining Material PTFE, Hard Rubber, Neoprene (as per media compatibility)
Communication Option HART, MODBUS, Profibus (optional)
Accuracy 0.5% of Reading
Minimum Conductivity of Fluid 5 S/cm
Electrode Material SS316 / Hastelloy / Titanium (optional)
Repeatability 0.2%
Process Connection Flanged (ANSI/DIN/BS), Others on request
Operating Temperature -10C to +80C (higher with special lining)
Power Supply 90-265 VAC or 24 VDC

Product Description

Capitalise on the ending soon opportunity to upgrade your system with our top-of-the-line Electromagnetic Flow Meters. Designed for liquid flow measurement, these meters deliver incomparable accuracy (0.5% of reading) and unmatched repeatability (0.2%). The lavish LCD with totalizer ensures instant readability while inestimable reliability is guaranteed with no moving parts, PTFE/hard rubber/neoprene linings, and corrosion-resistant construction. Flexible flanged process connections, IP65/IP68 ingress protection, and versatile outputs (4-20mA, pulse, MODBUS, HART, Profibus) cater to diverse industrial needs. Choose these low-maintenance, highly adaptable meters for robust performance in water treatment, chemicals, food & beverage, and pharma sectors.

Electromagnetic Flow Meters: Commercial Uses and Competitive Edge

Electromagnetic flow meters are a staple for industries including water treatment, chemical plants, pharmaceuticals, and food & beverage processing. Their specific usage lies in precise liquid flow measurement, offering maintenance-free operation and corrosion-resistant design. Competitive advantages such as customizable sizing, digital display, and versatile outputs set these meters apart in environments requiring stringent measurement accuracy and reliability, ensuring seamless integration into various commercial processes.

Electromagnetic Flow Meters: Delivery and Certification Information

Our logistics team swiftly manages delivery times, providing you with a precise estimate based on destination and order size. Standard FOB ports across India facilitate efficient shipments, minimising transit time and charges. Each electromagnetic flow meter is supplied with requisite certifications, guaranteeing compliance with international standards. Trust us for prompt, well-documented deliveries supported by robust logistic channels, enabling your operations to commence without delays.

FAQ's of Electromagnetic flow meters:

Q: How do electromagnetic flow meters ensure accurate measurements in industrial applications?

A: Electromagnetic flow meters operate using a magnetic field and electrodes to measure the flow rate of conductive liquids with a high degree of accuracy (0.5% of reading) and repeatability (0.2%), making them ideal for precise control in industrial processes.

Q: What output and communication options are available for these flow meters?

A: These meters feature standard 4-20mA and pulse outputs, with optional RS485 MODBUS, HART, and Profibus communication, enabling easy integration with various industrial automation and monitoring systems.

Q: When should I choose compact versus remote-type electromagnetic flow meters?

A: Compact types are suitable for installations with space constraints, placing electronics and sensors together. Remote types are preferred in environments with high vibration or temperature, separating the electronics from the sensor for optimal reliability.

Q: Where are these flow meters typically used?

A: These meters are deployed in water treatment plants, chemical industries, pharmaceutical production lines, and food & beverage processing, wherever there is a need for non-intrusive, maintenance-free, and highly accurate liquid flow monitoring.

Q: What is the process for selecting the right model and lining for specific fluids?

A: Selection depends on the conductivity and chemical properties of your process liquid. Our team assists in choosing the appropriate lining (PTFE, hard rubber, neoprene) and electrode materials (SS316, Hastelloy, Titanium) to ensure maximum compatibility and longevity.

Q: What are the benefits of electromagnetic flow meters over mechanical alternatives?

A: Electromagnetic flow meters contain no moving parts, reducing the possibility of mechanical wear, offering long-term reliability, lower maintenance costs, and superior accuracy across a wide range of flow rates and fluid types.
